12 CC BENT AXIS HYDRAULIC PISTON PUMP

MeWa Hydraulic 18 CC Bent Axis Hydraulic Piston Pump is designed for reliable and efficient hydraulic power transmission in demanding applications.

This high-performance Bent Axis Hydraulic Piston Pump is suitable for mobile and industrial hydraulic systems requiring consistent flow, reliable operation and efficient power transmission.

TECHNICAL HIGHLIGHTS

• 12 CC Displacement
• Bent Axis Hydraulic Piston Pump
• CODE : AXP007012BD
• Maximum continuous pressure: 400 bar
• Maximum intermittent pressure: 450 bar
• Maximum peak pressure: 450 bar
• Continuous speed: up to 2300 RPM
• Intermittent speed: up to 3100 RPM

For technical specifications, compatibility and application details, please contact MeWa Automotive.

Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Description

CODE DISPLACEMENT (CC) THEORETICAL OIL FLOW (LT/MIN) AT 1000 RPM THEORETICAL OIL FLOW (LT/MIN) AT 1500 RPM CONTINUOUS SPEED (RPM) LIMITED SPEED (RPM) MAX. CONT. PRESSURE (BAR) MAX. INT. PEAK PRESSURE (BAR) MAX. TORQUE AT 350 BAR WEIGHT (KG) INLET & OUTLET
AXP007012BD 12 12 18 2300 3100 400 450 71 9.4 3/4"
AXP007018BD 18 18 27 2300 2900 400 450 105 9.4 3/4"
AXP007025BD 25 25 37.5 2300 2700 400 450 145 9.9 3/4"
AXP007032BD 32 32 48 2250 2700 400 450 190 10.9 1"
AXP007040BD 40 40 55 1900 2500 400 450 240 10.9 1"
AXP007050BD 50 50 75 1900 2500 400 450 292 11.4 1"
AXP007063BD 63 63 94.5 1900 2300 400 450 360 11.9 1"
AXP007080BD 80 80 120 1700 2100 400 450 460 15.4 1"
AXP007108BD 108 108 16.6 1700 1900 400 450 620 15.9 1"
AXP007130BD 130 130 195 1600 1750 400 450 746 17 1"
