Mewa Hydraulic ISO 30-82 CC TANDEM Bi-Directional Gear Pump is designed for reliable and efficient hydraulic power transmission in demanding applications.
This 30 Series TANDEM gear pump provides bi-directional operation with a 82 cm³/rev displacement and UNI mounting configuration. It is engineered for consistent performance, robust operation and long service life in hydraulic systems.
Ideal for mobile and industrial hydraulic applications where reliable flow, pressure performance and compact installation are required.
TECHNICAL HIGHLIGHTS
• 30 Series Tandem Gear Pump
• 82 cm³/rev displacement
• ISO-TANDEM mounting configuration
• Bi-directional operation
• Maximum continuous pressure: 220 bar
• Maximum intermittent pressure: 240 bar
• Maximum peak pressure: 250 bar
• Continuous speed: up to 1400 RPM
• Intermittent speed: up to 1600 RPM
.
.
.
.
.
.
.
.
.
.
.
.
| CODE | PUMP TYPE | MAXIMUM CONT. PRESSURE (BAR/PSI) | MAXIMUM INT.PRESSURE (BAR/PSI) | MAXIMUM PEAK PRESSURE (BAR/PSI) | MAXIMUM CONT. SPEED (RPM) | MAXIMUM INT. SPEED (RPM) | INLET | WEIGHT | OUTLET | DISPLACEMENT (CM³/REV) |
|---|---|---|---|---|---|---|---|---|---|---|
| GP3061TNDBD | TANDEM 30-61 CC GEAR PUMP ISO BI-DIRECTIONAL | 240/3300 | 260/3600 | 260/3700 | 1400 | 1600 | G1 1/4" | 14 | G1" | 61 |
| GP3082TNDBD | TANDEM 30-82 CC GEAR PUMP ISO BI-DIRECTIONAL | 220/3190 | 240/3480 | 250/3625 | 1400 | 1600 | G1" | 15 | G1" | 82 |
