DPA 30-82 CC GEAR PUMP ISO BI-DIRECTIONAL

Mewa Hydraulic DPA 30-82 CC ISO Bi-Directional Gear Pump is designed for reliable and efficient hydraulic power transmission in demanding applications.

This 30 Series gear pump provides bi-directional operation with a 82 cm³/rev displacement and ISO mounting configuration. It is engineered for consistent performance, robust operation and long service life in hydraulic systems.

Ideal for mobile and industrial hydraulic applications where reliable flow, pressure performance and compact installation are required.

TECHNICAL HIGHLIGHTS

• 30 Series Gear Pump
• 82 cm³/rev displacement
• ISO mounting configuration
• Bi-directional operation
• Maximum continuous pressure: 190 bar
• Maximum intermittent pressure: 210 bar
• Maximum peak pressure: 220 bar
• Continuous speed: up to 1400 RPM
• Intermittent speed: up to 1600 RPM
.
.
.
.
.
.
.
.
.
.
.
.

Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Description

CODE PUMP TYPE MAXIMUM CONT. PRESSURE (BAR/PSI) MAXIMUM INT.PRESSURE (BAR/PSI) MAXIMUM PEAK PRESSURE (BAR/PSI) MAXIMUM CONT. SPEED (RPM) MAXIMUM INT. SPEED (RPM) INLET WEIGHT OUTLET DISPLACEMENT (CM³/REV)
GP3017ISOBD DPA 30-17 CC
GEAR PUMP ISO
BI-DIRECTIONAL		 290/4200 315/4560 325/4700 1400 1600 G 1/2" 11.5 G 1/2" 17
GP3027ISOBD DPA 30-27 CC
GEAR PUMP ISO
BI-DIRECTIONAL		 290/4200 315/4560 325/4700 1400 1600 G 3/4" 12.5 G 3/4" 27
GP3034ISOBD DPA 30-34 CC
GEAR PUMP ISO
BI-DIRECTIONAL		 280/4060 300/4350 310/4500 1400 1600 G 3/4" 13 G 3/4" 34
GP3043ISOBD DPA 30-43 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 270/3900 290/4200 300/4350 1400 1600 G 1" 13.5 G 3/4" 43
GP3051ISOBD DPA 30-51 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 240/3480 260/3770 280/4060 1400 1600 G 1" 14 G 1" 51
GP3061ISOBD DPA 30-61 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 220/3190 240/3480 250/3625 1400 1600 G1 1/4" 14 G 1" 61
GP3071ISOBD DPA 30-71 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 220/3190 240/3480 250/3625 1400 1600 G1 1/4" 14.5 G1" 71
GP3082ISOBD DPA 30-82 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 190/2750 210/3045 220/3190 1400 1600 G1 1/4" 14.8 G1" 82
GP3090ISOBD DPA 30-90 CC
GEAR PUMP
ISO
BI-DIRECTIONAL		 190/2750 210/3040 220/3190 1400 1600 G1 1/4" 15 G1" 90
