DPM 61 CC GEAR PUMP UNI WITH MECHANICAL CONTROL

Mewa Hydraulic DPM 30-61 CC UNI WITH MECHANICAL CONTROL Bi-Directional Gear Pump is designed for reliable and efficient hydraulic power transmission in demanding applications.

This 30 Series DPM gear pump provides bi-directional operation with a 61 cm³/rev displacement and UNI mounting configuration. It is engineered for consistent performance, robust operation and long service life in hydraulic systems.

Ideal for mobile and industrial hydraulic applications where reliable flow, pressure performance and compact installation are required.

TECHNICAL HIGHLIGHTS

• 30 Series Dpm Gear Pump
• 61 cm³/rev displacement
• UNI-DPM mounting configuration
• Bi-directional operation
• Maximum continuous pressure: 240 bar
• Maximum intermittent pressure: 260 bar
• Maximum peak pressure: 280 bar
• Continuous speed: up to 1400 RPM
• Intermittent speed: up to 1600 RPM
.
.
.
.
.
.
.
.
.
.
.
.

Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Description

CODE PUMP TYPE MAXIMUM CONT. PRESSURE (BAR/PSI) MAXIMUM INT.PRESSURE (BAR/PSI) MAXIMUM PEAK PRESSURE (BAR/PSI) MAXIMUM CONT. SPEED (RPM) MAXIMUM INT. SPEED (RPM) INLET WEIGHT OUTLET DISPLACEMENT (CM³/REV)
GP3043DPMBDU DPM 30-43 CC GEAR PUMP UNI BI-DIRECTIONAL 270/3900 290/4200 300/4350 1400 1600 G 1" 11.75 G 3/4" 43
GP3051DPMBDU DPM 30-51 CC GEAR PUMP UNI BI-DIRECTIONAL 240/3480 260/3770 280/4060 1400 1600 G 1" 12 G 1" 51
GP3061DPMBDU DPM 30-61 CC GEAR PUMP UNI BI-DIRECTIONAL 220/3190 240/3480 250/3625 1400 1600 G1 1/4" 13.5 G 1" 61
